SINOTRUK HOWO Bitumen Tank
Model data
Technical Specifications
Core Parameter Summary
| Parameter | Value |
|---|---|
| Drive Type | 8×4 Four-axle Dual-rear-axle Reinforced Structure |
| Overall Dimensions | 11950×2550×3450 mm |
| GVW | 31000 kg |
| Emission Standard | Euro 2 / Euro 3 / Euro 5 |
| Horsepower | Euro2:371HP；Euro3/Euro5:400 / 430HP Multiple Options |
Standard Export Parameters
| Item | Specification |
|---|---|
| Brand Series | SINOTRUK HOWO |
| Chassis Model | ZZ1317N4667C1 (LHD) / ZZ1317N4667C1R (RHD) |
| Drive Type | 8×4 dual rear axle drive |
| Wheelbase | 1800+4600+1350 mm |
| Curb Weight | 14800-15400 kg (after bitumen tank & full thermal-oil heating superstructure installation, subject to actual vehicle announcement) |
| Payload | Approx. 15600-16200 kg (GVW 31000 − curb weight, subject to actual vehicle announcement)<br>Note: Bitumen density varies with temperature, actual payload subject to local regulations |
| Max Speed | 80 km/h (electronic speed-limit for dangerous goods) |
| Max Gradient | 32% |
| Ground Clearance | 280 mm |
| Bitumen Tank Effective Volume | Effective tank volume 24-27m³; Q235B carbon-steel tank body, optional corrosion-resistant alloy lining; multi-layer aluminium-silicate thermal-insulation layer; internal thermal-oil heating coils; manhole, explosion-proof breather valve, emergency cut-off valve, overflow protection; multi-compartment optional; full set of dangerous-goods safety accessories |
| Bitumen Loading-unloading & Heating System | PTO-driven thermal-oil boiler closed-loop circulation heating system; controllable tank temperature 120-180℃; bitumen inlet-outlet pipeline, high-temperature ball valves, filter, drain port; optional independent burner & automatic temperature-control system; for liquid bitumen loading/unloading and constant-temperature storage |
| Fuel Tank | 400L aluminum alloy lightweight anti-corrosion fuel tank, 600L large-capacity tank optional for long-distance cruising |
| Engine | 6-cylinder turbocharged intercooled diesel engine; Euro2 mechanical pump version:371HP; Euro3/Euro5 electronic controlled version:400 / 430HP, featuring high torque and sufficient power reserve with stable operation for heavy-duty dangerous-goods engineering transport |
| Transmission | HW19710 10-speed manual gearbox with dedicated PTO port, reliable power transmission under heavy load, no clutch slippage, AMT automatic transmission optional for smooth shifting |
| Clutch | 430 mm diaphragm spring dry clutch with strong load capacity and high wear resistance for stable heavy-load starting |
| Axle Configuration | 9.5T reinforced double front axles + 16T double-reduction dual rear axles, professional heavy-duty configuration with optional gear ratio and excellent driving stability |
| Steering System | Hydraulic power steering with stable and accurate control and flexible operation |
| Brake System | Dual-circuit air brake, spring parking brake and Exhaust Brake, equipped with ABS anti-lock system for enhanced dangerous-goods braking safety, safe, stable and short-distance braking |
| Tire Specification | 12.00R20 / 12R22.5 heavy-duty tires, 12 running tires + 1 spare tire |
| Electrical System | 24V full-vehicle electrical system with dual 12V batteries in series; anti-static dangerous-goods circuit adapted for high-temperature working conditions, stable power supply for sensors and temperature-control devices |
| Cab | New HOWO single-sleeper all-steel cab with four-point floating suspension. Standard: air suspension driver seat, electric heating rearview mirrors, power windows, automatic air conditioner, multi-functional steering wheel, full-vehicle noise reduction and large-capacity storage space, delivering superior comfort and safety |
| Body Color | Standard factory colors: Engineering Yellow, HOWO White; optional dangerous-goods warning painting. Custom exclusive body colors available via original factory customization, featuring full-vehicle anti-corrosion and fade-resistant finish |
| Standard Accessories | High-position metal bumper, protective lamps, reverse warning device, full-vehicle anti-corrosion coating, air horn and headlight protection device, dangerous-goods warning signs, fire extinguisher, flame arrester, static-earthing device, tank access ladder |
| Parts Universality | Chassis, power, axle, brake and body parts are universal with full HOWO heavy-trucks series, featuring large overseas market stock, sufficient spare parts, convenient maintenance and low operating costs |
FAQ
Q1: Is the HOWO 8×4 bitumen tanker an original factory export model?
It is an officially designated export 8×4 dangerous-goods bitumen-tanker model of SINOTRUK HOWO series, built on brand-new original dangerous-goods heavy-duty chassis. Bitumen tank, thermal-oil heating system and full set of safety accessories are assembled complying with overseas dangerous-goods export standards. There is no domestic-market re-modification or non-standard refit, fully complying with global dangerous-goods vehicle access regulations.
Q2: Are spare parts universal for all versions?
All versions share the same four-axle heavy-duty dangerous-goods chassis, dual rear axles, gearbox and body parts, with only slight differences in engine accessories. Bitumen tank and thermal-oil heating pipeline assemblies are interchangeable for all horsepower variants, ensuring convenient global maintenance and high spare-parts popularity.
Q3: Is custom service available?
Original factory LHD/RHD customization, Euro 2 / Euro 3 / Euro 5 emission selection, bitumen tank volume, multi-compartment option, heating configuration(independent burner, auto temperature control), tank lining material and body-color customization are supported. LHD suits Africa, Central Asia, Middle East and South America; RHD suits Southeast Asia, Australia and Commonwealth regions.
Q4: How to choose Euro 2 / Euro 3 / Euro 5 versions?
Euro 2 mechanical injection version adapts to areas with poor fuel quality and simple maintenance conditions with low failure rate; Euro 3 and Euro 5 electronic versions meet high environmental-protection requirements with fuel-saving and eco-friendly performance.
Q5: What working conditions is each horsepower version suitable for?
371HP(Euro2) for medium-haul bitumen transportation for road-construction projects; 400HP(Euro3/Euro5) for long-distance bitumen material transport; 430HP(Euro3/Euro5) high-torque version for high-intensity transport on mountainous and steep-slope construction sites.
Q6: What are the core advantages of this model?
Equipped with reinforced 8×4 four-axle heavy-duty dangerous-goods chassis, it achieves 31-ton compliant GVW and high stability. Mature six-cylinder powertrain delivers sufficient power and high operational availability, low failure rate. The tank adopts closed-loop thermal-oil heating plus multi-layer thermal insulation to realize constant-temperature bitumen storage & transportation, with complete export-grade dangerous-goods safety protection. Multiple OEM customization options, globally-available spare-parts and low maintenance cost bring outstanding cost-performance for overseas road-construction liquid bitumen dangerous-goods transport.
