SINOTRUK HOWO Pure Electric Single-side Dock Tractor Trucks
Applicable Model: ZZ5187TXSEV (LHD) / ZZ5187TXSEVR (RHD)
Product Positioning: SINOTRUK HOWO pure-electric single-side dock yard tractor, 4×2 rear-wheel drive, specially designed for enclosed port and large-factory yard operation. Equipped with high-voltage LFP lithium-iron-phosphate battery, zero-emission and low-noise. Used for towing yard container semi-trailers and flat-bed trailers. For enclosed yard / dock-site use ONLY. NOT road-legal, NOT licensed for public-road driving.
Alternative Names: HOWO Pure-electric Yard Terminal Tractor, Port Electric Dock Tug, Export Industrial Yard Electric Tractor Unit.
Model data
Technical Specifications
Core Parameter Summary
| Core Parameter | Value |
|---|---|
| Drive Type | 4×2 Rear-wheel drive (yard-use only) |
| Overall Dimensions | 6480‑6520 × 2550‑2580 × 3360‑3400 mm |
| GVW | 18000 kg |
| Power Type | Pure-electric (LFP lithium-iron-phosphate battery) |
| Rated / Peak Power | 140 kW / 260 kW |
Standard Export Parameters
| Item | Specification |
|---|---|
| Brand Series | SINOTRUK HOWO Pure-electric Dock Tractor |
| Chassis Model | ZZ5187TXSEV (LHD) / ZZ5187TXSEVR (RHD) |
| Drive Type | 4×2 Rear-wheel drive for yard application |
| Wheelbase | 3600 mm【OEM sample value】 |
| Curb Weight | 8350‑8750 kg |
| Max Towing GCW | 38000 kg (Reference test value under flat enclosed dock-yard condition; subject to ground condition, battery SOC and actual load. Yard-reference only, NOT road-homologated towing capacity, must NOT be used for public-road towing) |
| Max Yard Speed | 25 km/h (electronic speed-limit for yard safety) |
| Max Gradient | ≥15% (full-load yard condition; for reference only, subject to ground adhesion) |
| Minimum Ground Clearance | 270 mm |
| Traction Battery System | LFP lithium-iron-phosphate battery; Standard 282 kWh; Optional 354 kWh; IP67 high-voltage protection; DC fast-charge supported; BMS battery-management-system; over-voltage, over-current and over-temperature protection |
| Drive Motor | Permanent-magnet synchronous motor; Rated 140 kW, peak 260 kW; water-cooled heat dissipation |
| Vehicle ECU System | VCU vehicle control unit; yard creep / low-speed mode; reverse audible-visual alarm; fault-diagnosis data storage |
| Transmission System | Special-purpose electric automatic transmission for yard duty; no traditional clutch; forward / reverse shift available |
| Axle Configuration | 9.5T steer front axle + 18T single-reduction heavy-duty rear drive axle; gear-ratio optimized for yard operation |
| Steering System | Hydraulic power steering for low-speed heavy-load yard maneuvering |
| Brake System | Dual-circuit air brake; spring parking brake; regenerative energy-recovery brake; ABS as standard |
| Fifth-wheel | Standard 2-inch(50#) yard-use fifth-wheel; optional 3.5-inch(90#) heavy-duty fifth-wheel; fifth-wheel is optional item; max vertical load 35000 kg |
| Tire Specification | Standard:12.00R20 heavy-duty yard tire; 6 running tires +1 spare tire; non-interchangeable wheel-rims for different sizes |
| Electrical System | 700V high-voltage battery system; 24V low-voltage auxiliary system; high-voltage inter-lock protection; insulation monitoring; reserved 7-core trailer electrical and air-hose coupling connectors |
| Cab | Single-side operator enclosed cab with 4-point floating suspension. Standard: damping seat, air-conditioner, power windows, reverse audio-visual alarm; human-machine layout optimized for yard-dock operation |
| Body Color | Standard factory colors: Engineering Yellow, HOWO White. Custom exclusive body colors available via original-factory customization; full-vehicle anti-corrosion coating |
| Standard Accessories | High-position metal bumper, protective lamps, reverse audible-visual warning device, full-vehicle anti-corrosion coating, high-voltage safety warning labels, high-voltage maintenance safety lock, tool-kit, spare tire |
| Certification Note | Overseas industrial-site safety certification available. Max speed, gradient and max towing GCW are yard-only performance reference values. Equipment for enclosed dock / factory yard ONLY, NOT road-licensable, forbidden for public-road driving. Australian industrial-equipment regulations are strict; factory base certification does not satisfy full Australian local compliance; additional local mandatory certification shall be confirmed for Australian projects. Fifth-wheel is optional. Subject to factory-out technical documents. |
| Parts Universality | Chassis running-gear, brake and body-parts are interchangeable with HOWO yard-equipment series. Mature overseas spare-part channels, convenient maintenance. |
| Gross Vehicle Weight | 18000 kg |
| Overall Dimensions (L×W×H) | 6480‑6520 × 2550‑2580 × 3360‑3400 mm |
| Approach / Departure Angle | 19° / 48° |
FAQ
Q1: Is the HOWO pure-electric single-side dock tractor an original-factory export-qualified unit?
It is original-factory export-qualified enclosed dock-yard only pure-electric tractor. Fifth-wheel is optional. This unit has no on-road motor-vehicle homologation, NOT licensed for public-road driving, only permitted inside enclosed port / factory premises. Manufactured to overseas industrial-equipment standards, no non-standard refit, complying with general overseas industrial-site safety requirements.
Q2: Are spare-parts universal among different battery-capacity variants?
All variants share identical chassis, axle, brake, cab and running-gear parts. Only battery pack and BMS parameters change with capacity options. Spare-parts are well-supported in overseas market.
Q3: Does it support customization and which markets does it suit?
Original-factory LHD/RHD customization available; customizable battery-capacity(282kWh /354kWh), fifth-wheel specification, tire pattern and body-color. LHD mainly suits Africa, Central Asia, Middle East and South America; RHD version available for Southeast-Asia. For Australian projects: customer shall complete additional local industrial-equipment certification; factory basic certification does not cover full Australian regulatory compliance.
Q4: How to select battery-capacity and charging-solution?
282 kWh standard version for medium-intensity shift-work in yard; 354 kWh large-capacity for long-duration continuous-operation. DC fast-charge is supported; site-side industrial DC charger with matching voltage-rating shall be prepared by customer. LFP battery features good temperature-resistance for heavy-load yard-working cycles.
Q5: What yard-working scenarios is this unit suitable for?
25 km/h top speed is safety-oriented for port-yard, not designed for high-speed driving. Suitable for towing yard container semi-trailers and flat-bed trailers. Max 38 t towing GCW is reference value for flat enclosed yard condition. Reduce speed under heavy-load climbing; keep ground dry to avoid slip. Not permitted for highway / public-road use.
Q6: What are core advantages of this yard tractor?
Zero-emission pure-electric power with low operating noise. IP67-protected LFP high-voltage battery set with complete high-voltage safety-protection measures. High-power permanent-magnet synchronous motor (140 kW rated / 260 kW peak), delivers good performance for heavy-load yard start-up and climbing. Regenerative brake for energy-saving. Single-side-optimized cab for frequent yard shunting & reversing. Multiple battery-capacity OEM custom options. Mature overseas spare-part supply channels. Well-suited for container and flat-bed trailer-towing in overseas ports and large enclosed industrial-sites.
